HPDAVV 15HP Gas Driven 30Gal ASME Tank Air Compressor 19cfm 180psi Welder & Generator
Product details
| Management number | 238279732 | Release Date | 2026/07/11 | List Price | $1,596.00 | Model Number | 238279732 | ||
|---|---|---|---|---|---|---|---|---|---|
| Category | |||||||||
<p>15HP Gas Driven Piston 30Gal ASME Tank Grade Belt Driven Air Compressor with LONCIN Engine 19cfm @ 180psi 3-In-1 Air Compressor Two-Stage Gasoline Welder & Generator<br> <br> Pump Material：Solid cast iron<br>Working Pressure：180 psi<br>Air flow：19 cfm<br>Pump Type：Two-Stage<br>Pump Drive：Belt Drive<br>Oil Type：Oil Lubricated<br>Oil System：Full Pressure Lubrication<br> <br> Welding output :40-200A<br> <br> Tank Size：30 Gallon / ASME<br>Tank Outlet：1/2 inch<br> <br> Working power：15 HP<br>Engine Brand：LONCIN/CH440<br>Starting System：120V/240Volt Key Start w/Recoil<br> <br> Max ACOUTPUT：6000watts<br>RatedAC：5400watts<br>Altermator Wattage：Cont.On-Load@90PSI / 3600watts<br>Altermator Wattage：Cont.On-Load@175PSI / 3000watts<br>Frequency/Voltage：60Hz/120V/240V<br>MAXAMPS(120V/240V)：41.5/20.8 off-Load<br>Cont.amps(120V/240V)：41.5/20.8 off-Load<br> <br> <br> 【Dependable LONCIN Gas Engine】<br> <br> Portable power produces 19cfm@180 psi, delivers a quiet operation and maximum reliability, LONCIN engine provides more power for easy starting, less fuel-use & lower emissions, easy to start, works hard, lasts a long time.<br> <br> <br> 【 Wide Application】<br> <br> The combination air compressor, generator, and arc welder is the ideal tool for field repairs in remote locations. Save room on your service truck with this versatile all-in-one solution.<br> <br> <br> 【AGW Series Operation】<br> <br> Generator Mode: AC current only. Selector switch set to idle down. Switch is set to full throttle. Welder Mode: DC current only. Engine must be running full throttle. Selector switch must be set to full throttle. Compressor Pump: Splash lubricated, Stainless-steel braided discharge hose, Large canister intake filter and Oil level sight indicator. Frame: Powder coated ASME coded receiver tanks. 14-gauge powder coated belt guard<br> <br> <br> 【Standard Warranty】<br> <br> HPDAVV provided with one-year parts warranty.</p>
- Parameters Power: 15 HP; Tank Output Pipe Diameter : 1/2”; Air Flow : 19 cfm; Max Working Pressure : 180 psi; Generator: 5.5 KW; Max KW : 6.5kw; Tank Capacity: 30 Gallons.
- Wide Application The combination air compressor, generator, and arc welder is the ideal tool for field repairs in remote locations. Save room on your service truck with this versatile all-in-one solution.
- Dependable LONCIN Gas Engine Portable power produces 19cfm@180 psi, delivers a quiet operation and maximum reliability, LONCIN engine provides more power for easy starting, less fuel-use & lower emissions, easy to start, works hard, lasts a long time.
- AGW Series Operation Generator Mode: AC current only. Selector switch set to idle down. Switch is set to full throttle.
- Welder Mode: DC current only. Engine must be running full throttle. Selector switch must be set to full throttle.
- Compressor Pump: Splash lubricated, Stainless-steel braided discharge hose, Large canister intake filter and Oil level sight indicator. Frame: Powder coated ASME coded receiver tanks. 14-gauge powder coated belt guard.
| Cfm | 19 |
|---|---|
| Volume capacity | 30 gal |
| Horsepower | 15 HP |
| Maximum psi | 180 psi |
| Power type | Gas |
| Number of stages | 1-Stage |
| Air compressor pump type | Oil-lubricated |
| Air compressor tank type | Two Stage |
| Brand | Hpdavv |
| Features | Portable |
| Volts | 120 V |
| Amps | 200 Amps |
| Material | Solid Cast Iron |
| Color | Black |
| Model | HSJQY051800 |
| Watts | 6000 Watts |
